Détails du produit

The Dahua IPC-HFW2449M-SB-PRO delivers professional-grade surveillance with a 4-MP 1/1.8" CMOS sensor optimized for low-light environments. Capable of 4MP output at 20 fps and 2K resolution at 25/30 fps, it employs H.265 codec technology for superior compression and minimal bandwidth consumption. The integrated warm light reaches 50m, ensuring visibility across expansive areas. Advanced features include ROI functionality, Smart H.264+/H.265+ encoding, WDR, 3D noise reduction, and intelligent detection modes—intrusion alerts and tripwire monitoring with vehicle/human classification. Comprehensive abnormality detection encompasses motion, video tampering, and audio analysis, making it ideal for demanding surveillance applications requiring reliability and efficiency.

The Dahua IPC-HFW2449M-SB-PRO features a premium 1/1.8" CMOS sensor delivering 2688 × 1520 resolution with exceptional low-light performance at 0.0001 lux. Progressive scanning and electronic shutter speeds from 1/3s to 1/100,000s provide precise exposure control across dynamic lighting conditions. Choose between 3.6mm (94° H-FOV) or 6mm (58° H-FOV) fixed-focal lenses with F1.0 aperture for superior light gathering. Four integrated warm-light illuminators extend visibility up to 50 meters, while 128MB ROM and 256MB RAM support advanced processing. With DORI distances reaching 70.3m detection and 28.1m observation capability at 3.6mm, this camera delivers professional-grade surveillance clarity. Signal-to-noise ratio exceeding 56dB ensures clean imagery in challenging environments.

Specifications:

Image Sensor

1/1.8" CMOS

Maximum Resolution

2688 (H) × 1520 (V)

ROME

128 MB

R.A.M.

256 MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual 1/3s-1/100,000s

Minimum illumination

0.0001 [email protected]

S/N Ratio

>56 dB

Illumination Distance

Up to 50 m (164.04 ft) (Warm light)

Illuminator On/Off Control

Auto; Manual

Illuminator Number

4 (Warm light)

Lens

Lens Type

Fixed-focal

Lens Mount

M16

Focal Length

3.6 mm; 6 mm

Maximum Aperture

F1.0

Field of View

3.6mm: H: 94°; V: 50°; D: 113°

6mm: H: 58°; V: 31°; D: 67°

Iris Control

Fixed

Close Focus Distance

3.6 mm: 3 m (9.84 ft)

6 mm: 6 m (19.69 ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

3.6 mm

70.3 m (230.64 ft)

28.1 m

(92.19 ft)

14.1 m

(46.26 ft)

7.0 m

(22.97 ft)

6 mm

116.6 m

(382.55 ft)

46.6 m

( 152.89 ft)

23.3 m

(76.44 ft)

11.7 m

( 38.39 ft)
DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.

Intelligence

IVS (Perimeter Protection)

Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)

SMD

SMD Plus

Smart Search

Work together with Smart NVR to perform refined intelligent search, event extraction, and merging to event videos

video

Video Compression

H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)

Smart Codec

Smart H.265+; Smart H.264+

Video Frame Rate

Main stream: 2688 × 1520@(1-20 fps)/2560 × 1440@(1-25/30 fps)

sub stream: 704 × 576@(1-25 fps)/704 × 480@(1-30 fps)

*The values above are the max. frame rates of each stream; for multiple streams, the values will be subject to the total encoding capacity.

Stream Capability

2 streams

resolution

4M (2688×1520/2560×1440); 3M (2304×1296); 1080p (1920×1080); 1.3M (1280×960); 720p (1280×720); D1 (704×576/704×480); VGA (640×480); CIF (352 × 288/352 × 240)

Bit Rate Control

VBR;CBR

Video Bit Rate

H.264: 32 kbps–6144 kbps;

H.265: 12 kbps–6144 kbps

Day/Night

Color/B/W

BLC

Yes

HLC

Yes

WDR

120 dB

White Balance

Car; natural; street lamp; outdoor; manual; regional custom

Gain Control

Auto/Manual

Noise Reduction

3D NR

Motion Detection

OFF/ON (4 areas, rectangular)

Region of Interest (RoI)

Yes (4 areas)

Smart Illumination

Yes

Image Rotation

0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower)

Mirror

Yes

Privacy Masking

4 areas

LDC

Yes

Audio

Built-in microphone

Yes, built-in mic

Audio Compression

G.711a; G.711Mu; PCM; G.726

alarm

Alarm Event

No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; SMD; security exception

Network

Network Port

RJ-45 (10/100 Base-T)

SDK and API

Yes

Network Protocol

IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNA; DDNS; QoS; UPnP; NTP; multicast; ICMP; IGMP; NFS; PPPoE; P2P; Bonjour; Auto Registration

Interoperability

ONVIF (Profile S & Profile G & Profile T); CGI

User/Host

20 (Total bandwidth: 48 M)

Storage

FTP; SFTP; Micro SD card (support max. 256 GB); NAS

browser

IE; Chrome; Firefox

Management Software

Smart PSS Lite; DSS; DMSS

Mobile Client

iOS; Android

Security

Digest;WSSE;Account lockout;Security logs;IP/MAC filtering;Generation and importing of X.509 certification;syslog;HTTPS;802.1x;Trusted boot;Trusted execution;Trusted upgrade;Session security;Security warning

Certification

Certifications

CE-LVD: EN62368-1;

CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU

power

Power Supply

12 VDC; PoE

Power Consumption

Basic: 2.0W (12VDC); 2.5W (PoE);

Max: 5.7W (12VDC); 6.8 W (PoE) (H.265+ intelligence on + WDR + illuminator intensity)

Environment

Operating Temperature

–40°C to +60°C (–40°F to +140°F)

Operating Humidity

≤95% (RH), non-condensing

Storage Temperature

–40°C to +60°C (–40°F to +140°F)

Storage Humidity

≤95% (RH), non-condensing

Protection

IP67

Structure

Casing material

Metal + plastic

Product Dimensions

201.0 mm × 103.8 mm × 97.8 mm (7.91" × 4.09" × 3.85") (L × W × H)

Net Weight

0.68 kg (1.50 lb)

Gross Weight

1.27 kg (2.80 lb)
